key specs
| LCD | 2.4inch TFT 320*240 |
| USB Port | Type-C, USB3.1, support data transfer |
| Button | Power Key, Menu_Select Key, Menu_Confirm Key, Reset(Hidden) |
| External Antenna | 1 x TS-9 connector for Tx/RX |
| 1 x TS-9 connector for Rx | |
| Card slot | One 4FF (Nano) UICC/USIM, push slot. |
| Battery | 4500mAh Li-on un-removable |
| Size | 138*72.4*17mm |
| Charger Power | 15W(5V/3A)/18W(9V/2A@PD) quick charging |
| Weight | 200g |
Block Diagram
RF functions
|
Cellular |
5G/LTE |
Qualcomm Snapdragon X62 |
|
Standard compliant: 3GPP Release 16(both LTE and 5G) |
||
|
Supported: LTE: B1/3/5/7/8/20/28/32/71/38/40/41/42/43 |
||
|
Modulation： Sub-6 UL: 256QAM, DL: 256QAM LTE DL:256QAM, UL:256QAM |
||
|
MIMO: Sub-6 DL: 4×4, UL: 2×2 LTE DL: 4X4, UL:1X1 |
||
|
Antenna(both LTE and 5G): 4 internal antennas |
||
|
Peak data rate: NSA 3.4Gbps@DL, 550Mbps@UL； SA：2.4Gbps@DL, 900Mbps@UL； |
||
|
Output power class: WCDMA: Class 3 (23 dBm ±2 dB) LTE-FDD: Class3(23dBm±2dB) LTE-TDD: Class3(23dBm±2dB) LTE B38/B41/B42/B43 HPUE: Class 2 (26 dBm ±2 dB) 5GNR:Class3(23dBm±2dB) 5G NR n38/n41/n77/n78 HPUE: Class 2 (26 dBm +2/-3 dB) |
||
|
Wi-Fi |
QCA2064 |
|
|
Standard compliant: IEEE 802.11 a/b/g/n/ac/11ax |
||
|
2.4 GHz (2×2 MIMO) +5.8G band (2x2 MIMO) |
||
|
AX1800 |
||
|
Antenna Gain |
Cellular Gain: 3.9dBi |
|
|
WiFi Gain: 4.1dBi |
||
Environment
| Temperature | Operating: 0°C to 40°C |
| Storage: -20°C to 60°C | |
| Humidity | Operating Humidity: 5 to 95% RH |
| Storage Humidity: 5 to 95% RH | |
| Non-condensing |
Features
| System Features | Web UI/Multiple language supported |
| SMS/Quota/APN/PIN Management | |
| Network Selection | |
| Data Usage / Statistic | |
| DHCP Server | |
| NAT | |
| IP Firewall | |
| Proxy DNS | |
| Security – SIM Lock and Secure boot features. | |
| Firewall – DMZ/MAC Filter/IP Filter/URL Filter/Port Filter | |
| Wi-Fi AP Features | 802.11 a/b/g/n/ac/ax/ 2.4GHz+5.8GHz |
| MU-MIMO | |
| Dual Band Combine SSID | |
| Auto Channel Select (ACS) | |
| Wi-Fi Enabled Device: up to 32 | |
| Hidden SSID | |
| Security Modes : Open, WPA2-PSK, WPA-PSK /WPA2-PSK, WPA3-SAE, WPA2-PSK /WPA3-SAE with AES | |
| Access Control : STA blacklist/white list | |
| WPS : Pin and PBC, WPS2.0 |
Dimension
Casing Dimension (WxDxH): 138*72.4*17mm
Accessories
| USB Cable | Type_A to Type_C USB cable |
| QSG | Quick start guide |
| Safety warning | Safety warning |
| Warranty card | Warranty card |
| DoC | Declaration of Conformity |
Packing
| Box | Box label |
| Inner paper | |
| Inner box | |
| Color box | |
| Carton | Carton label (carton label + battery warning label) |
| Carton | |
| Pallet | Pallet label |
| Pallet |
