Blazing 5G mmWave Speeds. Industrial-Grade Outdoor CPE for Challenging Environments
Product Overview
The O022 is a powerful ourdoor 5G CPE that supports Sub-6GHz bands (e.g. N40, N41, N78, N79),delivering high-speed,lowplatency wireless connectivity.
Built for enterprise and carrier-grade installstions,it enables gigabit-class brodband for fixed wireless access(FWA),edge computing,and smart campus networking.
Featuring advanced beam tracking,BLE-assisted self-installation,and enterprise-grade security and management,the O022 ensures quick deployment and stable performance-even in congested urban zones or remote field locations.
- High-Performance Sub-6GHz 5G
Reliable coverage and fast speed with multi-antenna design. - Beamforming Antennas
Includes omni-directional and directional antennas for strong, stable signal reception. - BLE Setup Assistant
Bluetooth app guides easy, tool-free installation. - Enterprise Interfaces
2.5GbE PoE (802.3AT), USB-C, remote management, and robust security.
Key Features
Sub-6GHz 5G Connectivity
High-Gain Antenna with Signal Tracking
BLE 5.0 Guided Setup App
2.5GbE PoE Input & USB-C Port
Remote TR-069 & FOTA Management
Built-in VPN, Firewall Support
Application Scenarios
The O022 is buitl to meet the demands for modem outdoor connectivity across a wide range of industries:
- Rural and Urban Broadband(FWA)
Deliver reliable,fiber-liker interet speeds without ternching. - Enterpise Network Backup
Secure failover connectivity for critical infrastructure and remote locations. - Smart Campus & Business Parks
Rapid deployment of high-speed acces across large outdoor spaces. - Industrial IoT & Surveillance
Power edge devices and real-time data applications with strong uplink capacity. - 5G Testbeds & Commercial Rollouts
Deploy scalable Sub-6GHz coverage for next-generation wireless projects.
FAQ
It supports 5G Sub-6GHz bands only (e.g. N40, N41, N78, N79).
Yes. With an IP-rated enclosure, it operates reliably from -20℃ to 60℃.
Yes. It supports 2.5GbE PoE (IEEE 802.3AT).
Yes. Remote management via TR-069 and FOTA is supported.
Yes. It is designed to complement edge computing deployments.
Specifications
| Item | Description |
| Model Name | O022 |
| Antenna | 4x omni-directional antennas-For Sub-6/LTE 1x mmWave antenna – QTM 547 |
| BLE | BLE 5.0 for APK/APP on installation assistant |
| Physical Interface | 1*2.5GE(PoE 802.3AT) USB Type-C |
| Dimensions | 225*130*45mm |
| Features | TR069 Traffic monitoring DHCP DNS DDNS Port-Forwarding uPnP Firewall FOTA VoLTE CSFB Dual WAN Admin from WAN VPN Passthrough DMZ Onekey Diagnostics |
