Industrial-Grade 5G Outdoor ODU – C120
Wewins C120 is a rugged industrial-grade 5G outdoor CPE router designed for high-performance Fixed Wireless Access (FWA) and Mobile Broadband (MBB) deployments.
Powered by the Qualcomm SDX55 platform and compliant with 3GPP Release 15, it delivers ultra-fast, low-latency connectivity in harsh outdoor environments. With support for global 5G Sub-6GHz bands, PoE power supply, and IP65-rated weatherproof housing, C120 is the ideal solution for remote enterprise sites, rural broadband, construction fields, and smart city infrastructures.
5GMBB&FWA-ODU-C120
- Global 5G/4G Compatibility
Supports Sub-6GHz bands (NSA & SA) for seamless worldwide deployment - High-Gain Antenna System
8 omni + 2 directional antennas deliver extended signal coverage and performance - IP65-Rated Outdoor Enclosure
Weatherproof and lightning-protected (6kV), ideal for harsh environments - Easy PoE Installation
Pole and wall-mount ready with Power-over-Ethernet for fast setup - Industrial-Grade Connectivity
Built for smart cities, rural broadband, industrial IoT, and remote deployments
Note: The bracket may be varied due to different installation requirement.
Key Features
2.5G Ethernet
Wide Temp Range
IP65 Rated
High-Gain Antennas
PoE Powered
Global 5G
Application Scenarios
C120 5G Outdoor CPE is an industrial-grade, high-performance 5G wireless router engineered for outdoor connectivity in harsh environments. Powered by the Qualcomm SDX55 chipset and supporting global 5G NR Sub-6GHz bands (NSA/SA, 3GPP Release 15), it ensures strong compatibility across international markets.
With high-gain antennas, IP65-rated weatherproof casing, and 6kV lightning protection, the C120 delivers reliable 5G fixed wireless access in rugged deployment scenarios. It is ideal for applications such as smart city surveillance, remote industrial IoT, rural broadband coverage, edge computing, and outdoor connectivity for energy, agriculture, and public safety sectors.
Certifications & Compliance
C120 5G Outdoor CPE is certified for global deployment, meeting rigorous standards for safety, performance, and environmental protection.
✔️ CE | ✔️ FCC | ✔️ RoHS | ✔️ IP65 | ✔️ 6kV Surge Protection
Specifications
| Item | Description |
| Platform | Qualcomm Snapdragon X55 |
| Network support | 5G/4G multi-mode, allows to use 4G as an alternative connection SA&CAT:-5G NSA/SA network. |
| SA&CAT | -5G NSA/SA network. |
| LTE Band width | 5G NR up to 200MHz |
| MIMO | 4 x 4 MIMO downlink and 2 x 2 MIMO uplink |
| BLE | BLE 5; -Configuration over BLE |
| Antenna | -4 omni-directional antennas for 360° Signal reception. 2 enhanced directional antennas |
| Physical Interface | -1 2.5GE LAN port. -1 Micro Sim slot.-1 Reset Key.-1 USB Type-C port. |
| Power Supply | Passive PoE: DC 48V/0.5A |
| Environmental | "1：IP65 2：Working Range -20 to 55°C 3：Lightning Surge Protection 6KV" |
| Size | 225*130*45mm 792.6g |
FAQ
When the device is working, press the reset button for more than 3 seconds until the indicator starts to blink. About 30 seconds later the indicator stops blink that means device complete the reset.
Restore the device and use the default Wi-Fi password and login password to try again.
- Please check if the SIM card is inserted.
- Please check if your SIM card is out of service.
- Please check there is any wrong about network connection steps.
- Ensure your computer is connected to the device through an Ethernet cable or Wi-Fi.
- Ensure your computer is set to obtain an IP address and DNS server address automatically.
- Restart your browser, or try another browser.
- If the problem persists, restore the device to its factory settings.
Operating environment
- Ideal operating temperatures are 0℃to 40℃. Ideal storage temperatures are -20℃ to +60℃.
- Keep the device away from heat and fire.
