| Cellular | LTE CAT-4 B3/B5/B40 based on Qualcomm MDM9207 |
| GPS | GPS/AGPS (MDM9207 build-in GPS Engine) |
| BLE | Nordic nRF52810. BLE 5.0 – It is for short range use case. (* BLE is DNP design) |
| Antennas | 3 Antennas (* BLE is DNP design) 1 LTE Antenna for Main (No diversity)/1 GPS Ceramics Antenna/1 BLE Antenna(DNP) |
| Sensor | 3 axis Accelerometer |
| Power Backup | Rechargeable and Not removable polymer battery – 200mAh / -10 to 60° C discharging – backup time around 2 hours, it depends on the actual use cases. |
| SIM | Embedded SIM MFF2 (DIM) |
| LEDs | 2 LEDs – LTE Indicator and GPS Indicator |
| IP Rating | IP65 |
| Interface | 10 Pins – VCC/Ground (9V – 90V) – ACC – DI * 1; DO * 2 ; – 1* Serial interface (Can be used for USB Debugging) |
| Operating Voltage | 9V-90V |
| Environmental | – Operation: -10° C up to 70° C (Battery discharging range is -10 to 60° C) – Storage: -20° C up to 85° C |
